Combination Windows - 2-Wide, Transom, Split

Combination Windows - 2-Wide, Transom, Split

Set of scaled dimensioned drawings of  2-Wide Split Transom Combination Windows viewed from the front, plan, and side
Description
Description

The 2-Wide Split Transom combination window is a refined design that features two vertical panels in a single horizontal row, each adorned with an individual transom in the second row. This two-panel-wide layout seamlessly integrates form and function, permitting an ample amount of natural light and providing unobstructed views. The distinct panels allow for customization in glazing and frame materials, complementing a variety of architectural styles.

The 2-Wide Transom combination window is an excellent choice for adding a unique design element or enhancing smaller spaces, delivering both practicality and aesthetic sophistication. This visually appealing window selection boosts curb appeal and creates an inviting focal point, making it a delightful addition to any home.

Dimensions & Sizes
Dimensions & Sizes

2-Wide Split Transom Combination Windows are available in a range of sizes with overall widths between 4’2”-8’2” (1.27-2.49 m), heights ranging from 5’4”-9’4” (1.62-2.84 m), and an overall sill depth of 5” (12.7 cm).

Group of illustrations of  2-Wide Split Transom Combination Windows in front views with different sizes
Group of illustrations of  2-Wide Split Transom Combination Windows in front views with different sizes
3D Model
3D Model
Common Questions
Common Questions
Perspective view of a 3D model of  2-Wide Split Transom Combination WindowsCombination Windows - 2-Wide, Transom, Split
Details
Details

*Under Development*

Height:
5’4”-9’4” | 1.62-2.84 m
Width:
4’2”-8’2” | 1.27-2.49 m
Depth:
5” | 12.7 cm
Length:
:
:
Weight:
Area:
:
Materials:
Wood, aluminum, insulating glass
:
:

Drawings include:

2-Wide Split Transom Combination Windows front elevation (various sizes), side view, plan views

Combination windows, also known as dual or hybrid windows, are a type of window that combines two or more different window styles or functions in one unit. For example, a combination window may feature a fixed picture window alongside a sliding or double-hung window for ventilation.

5’4”-10’4” | 1.62-3.15 m
4’2”-8’2” | 1.27-2.49 m
5” | 12.7 cm
