IKEA Norddal Bunk Bed

IKEA Norddal Bunk Bed

Collection of drawings of the IKEA Norddal Bunk Bed with dimensions for height, clearance, length and width
Description
Description

The IKEA Norddal Bunk Bed is a set of simple stacked lacquered bed frames that can be disconnected as two separate single beds. Designed by Henrik Preutz for IKEA as a flexible and clean-lined sleeping solution with a ladder that can be mounted on either side, the IKEA Norddal Bunk Bed is convenient for limited living spaces.

Dimensions & Sizes
Dimensions & Sizes

The IKEA Norddal Bunk Bed is designed for twin mattresses and has a length of 77.75” (198 cm), width of 40.125” (102 cm), and height of 63” (160 cm).

3D Model
3D Model
Common Questions
Common Questions
View of the IKEA Norddal Bunk Bed in 3D available for downloadIKEA Norddal Bunk Bed
Details
Details

*Under Development*

Height:
63” | 160 cm
Width:
40.125” | 102 cm
Depth:
Length:
77.75” | 198 cm
:
Clearance Below:
27.75” | 71 cm
Weight:
Area:
21.6 ft2 | 2 m2
:

Max Weight Load: 220 lb | 100 kg
Bed Size: Twin

Materials:
Solid pine structure; fiberboard panels; steel support rail
Designer:
Henrik Preutz (IKEA)
Year:
2013

Drawings include:
IKEA Norddal Bunk Bed front elevation, front (children), side, plan

Bunk Beds are common types of bed systems made up of two or more beds stacked on top of each other. Efficiently utilizing the unused vertical space above the same area occupied by a single bed, bunk beds are structured to safely support two people sleeping simultaneously.

71.625” | 182 cm
41.5” | 106 cm
77.5” | 197 cm
21.9 ft2 | 2 m2
2017
