Jalousie Window - 3 Panels, Wide Slats

Jalousie Window - 3 Panels, Wide Slats

Scaled set of drawings of the Jalousie Window (3 Panels, Wide Slats) in front, side and top views
Description
Description

A triple panel jalousie window with wide slats is a window design that consists of three horizontal panels with adjustable wide slats. The slats can be made of various materials such as glass, wood, or metal and are operated using a crank or lever. When the crank is turned, all three panels can be opened or closed simultaneously, providing maximum flexibility in controlling ventilation and sunlight.

The wide slats allow for greater airflow but may compromise the window's energy efficiency due to increased air leakage. This design is commonly used in warm and humid climates, where good ventilation is a priority. However, it may not be suitable for colder climates due to the potential for increased energy loss.

Dimensions & Sizes
Dimensions & Sizes

The Jalousie Window (3 Panels, Wide Slats) is available in a range of sizes with widths between 7’-12’ (213-366 cm), heights ranging from 2’4”-6’4” (71- 193 cm), and an overall frame depth of 5” (12.7 cm).

Series of illustrations of the Jalousie Window (3 Panels, Wide Slats) seen from elevation views with varied sizes
Series of illustrations of the Jalousie Window (3 Panels, Wide Slats) seen from elevation views with varied sizes
3D Model
3D Model
Common Questions
Common Questions
3D model of a Jalousie Window (3 Panels, Wide Slats) viewed in perspectiveJalousie Window - 3 Panels, Wide Slats
Details
Details

*Under Development*

Height:
2’4”-6’4” | 71- 193 cm
Width:
7’-12’ | 213-366 cm
Depth:
5” | 12.7 cm
Length:
:
:
Weight:
Area:
:

Width (Slats): 6” | 15 cm

Materials:
Glass, vinyl or wood slats; aluminum or wood frame
:
:

Drawings include:

Jalousie Window (3 Panels, Wide Slats) front elevation (various sizes), side view, plan views

Jalousie windows, also known as louvered windows, consist of horizontally mounted slats that can be adjusted to control the amount of airflow into a building. The slats can be opened or closed using a crank or lever, and the angle of the slats can also be adjusted to allow varied sunlight.

2’4”-6’4” | 71- 193 cm
2’4”-4’ | 71-122 cm
5” | 12.7 cm
